Galvanized steel plates measuring one-quarter inch minimum are anchored to concrete masonry unit jambs and lintels using post-installed anchors sized per schedule. Post-installed anchors are staggered as necessary to ensure only one anchor is located within a single masonry cell. Dimensions and spacing are coordinated per architectural requirements.
NOTES: 1. SEE A-622 FOR JAMB DETAILS, LOCATIONS, AND ADDITIONAL INFORMATION. 2. STAGGER POST INSTALLED ANCHORS AS NECESSARY SUCH THAT ONLY ONE ANCHOR IS LOCATED WITHIN A CELL. COORDINATE WITH OTHER MASONRY LINTEL DETAILS. PER ARCH GALV PL1/4 MIN PI AHR PER SCHED PER ARCH GALV PL1/4 MIN PI AHR PER SCHED LINTEL JAMB
