A stepped concrete foundation wall bears on a continuous concrete footing. Vertical and horizontal wall reinforcing ties into the footing via minimum dowels matching the wall reinforcement size. Continuous Z bars match the continuous footing reinforcement across the step. A continuous 2x4 keyway is embedded at the cold joint between the footing and the foundation wall. Step dimensions and footing sizes are governed by schedules.
3'-4" MAXIMUM "t" SEE SCHEDULE "t" = (2x STEP HEIGHT MINIMUM) "t" MIN. DOWELS TO MATCH VERT. AND HORIZ. WALL REINFORCING 2x4 KEYWAY CONT. "Z" BARS TO MATCH CONT. FOOTING REINF. CONT. CONCRETE FTG, SEE FOOTING SCHEDULE FOR SIZE & REINF. CONCRETE FOUNDATION WALL - SEE SCHEDULE
