A twelve-inch wide haunch plate is welded to the structural steel member, with the web slotted around the plate for the specified haunch plate length. The connection is detailed with specified weld sizes and dimensions measured from the grid or centerline of support. Cross-sectional views detail the twelve-inch width of the haunch plate relative to the structural member flange.
B 12" WIDTH HAUNCH PL SECTION A 1 GRID OR CL OF SUPPORT SEE PLAN FOR LOC SLOT PL AROUND WEB FOR HAUNCH PL LENGTH DEPTH ES WELD WELD MARK 13 1/4" D 12" WIDTH HAUNCH PL WELD WELD LENGTH, SEE PLAN
