This structural plan details a reinforced concrete pile cap with column centerlines and dimensioned spacing. The main reinforcement consists of 25M rebars spaced at 200 millimeters on top and bottom in one direction, and 25M bars at 150 millimeters top and 200 millimeters bottom in the perpendicular direction. Additional side-face reinforcement of 15M rebars at 200 millimeters spacing is provided along exposed pile cap edges. Column locations are referenced to centerlines, with column sizes and details coordinated per the structural plans and schedules.
25M@200T 25M@200B 25M@150T 25M@200B CLCOLUMN CLCOLUMN CLCOLUMN MB-A 900 1500 1500 900 900 900 900 900 4800 3600 NOTE: PROVIDE 15M@200 SIDE-FACE REINFORCEMENT ALONG EXPOSED PILE CAP EDGES. FOR COLUMN, SEE PLANS AND SCHEDULE (TYP)
