A cold-formed steel wall connects to a continuous bent plate using a SCAFCO PLC4 clip fastened with two number fourteen SCAFCO shouldered screws and three self-drilling screws installed at an angle. The assembly bears on a steel joist supported by a steel beam.
SCAFCO PLC4 CLIP W/ (2) #14 SCAFCO SHOULDERED SCREWS 7 (3) SELF-DRILLING SCREWS AT ANGLE SEE ARCH. CFS WALL CONT. BENT 5 - SEE 8 S5.12 STL BM STL JST FOR DETAILS & CALLOUTS IN COMMON SEE 3 S5.11
