A concrete beam measuring twenty-four inches by fifty inches frames into a concrete wall per plan. The assembly is reinforced with two rows of seven number eight bars at the top, two rows of seven number nine bars at the bottom, and number five skin reinforcement typically placed around the perimeter. Number four stirrups enclose the section at twelve inches on center.
50" 24" 2 ROWS OF (7)#9 CONCRETE BEAM PER PLAN 2 ROW OF (7)#8 CONCRETE WALL PER PLAN #5 SKIN REINF, TYP #4 STIRRUPS @12" OC
