An embed plate is anchored using seven-eighths-inch diameter by two-foot-long heavy welded stud anchors arranged in a specific layout. A typical side plate is welded along the perimeter of the embed plate. Symmetrical dimensions of three inches, six inches, and eight inches govern the anchor and stud spacing.
STUD LAYOUT 4 3" 8" 8" 6" 3" 3" 6" 6" 3" 3" 8" 8" 6" 3" 3" 6" 6" 3" EMBED PL SIDE PL - TYP 7/8" ⌀ X2'-0" HWS ANCHORS 1'-6" 1'-6" "N e " "B e "
