Structural · S-A575E

Typical Interior Concrete Column and Wall Slab Edge Details

Materials

Concrete

Elements

Columns Walls Floors / Slabs Foundations / Footings Arches Anchors / Embeds Reinforcing

Connections

Rebar Splice / Development

About this detail

Structural concrete slab-on-grade conditions intersect a concrete wall and a concrete pile cap. The eight-inch slab on grade features a two-inch thickened edge extending thirty-six inches at the wall and pile cap per plan. Number four dowels measuring three feet six inches in length are spaced at eighteen inches on center. Vertical wall and column reinforcing dowels match the reinforcement size specified in the structural plans and schedules. Column ties are provided per schedule.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
