Roof level wide-flange beams frame into a wide-flange column using typical simple connections. The connection includes web plates, half-inch thick cap plates, and horizontal stiffener plates matching the web plate thickness. Weld symbols indicate partial-joint-penetration welds typically used throughout, along with three-eighths-inch fillet welds for attaching the cap plate to the column web. Working points, slope requirements, and connection schedules are referenced for proper alignment and sizing.
