Hollow structural section girts frame into a wide flange steel column using welded end plates and angle connections. The connection utilizes HSS10.75 and HSS12x8 members fitted with three-eighths-inch thick end plates welded with one-quarter-inch fillet welds. L4x4x1/2 angle clips measuring zero feet six inches long attach with two seven-eighths-inch diameter A325 bolts centered on the column and girt. One-half-inch full width stiffener plates are welded inside the column flanges to transfer loads.
SECTION BELOW 7" 7" L4x4x1/2x0'-6" W/ (2) 7/8" ⌀ A325 BOLTS CENTERED ON COL/GIRT (TYP) 1/4 END PL TYP HSS10.75 GIRT - SEE PLAN W/ 3/8x12x1'-0" END PL (TYP) HSS12x8 GIRT - SEE PLAN W/ 3/8x9x1'-1" END PL @1A 1/4 TYP 1/2" STIFFNER PL FULL WIDTH (TYP) WF COLUMN SEE COL SCHED PLAN SECTION 3 1/2" T/STEEL SEE PLAN 1/2" STIFFNER PL FULL WIDTH (TYP) 1/4 4 TYP
