Text on the drawing
U/S OF DECK - HIGH POINT 108.48 CLT, SEE PLAN BEAM TO GLULAM CONNECTION. GLULAM SUPPLIER TO DESIGN FOR FACTORED SHEAR FORCE OF: Vf = 100 kN HSS 102x102x6.4 W/ 4-19DIA BOLTS LOWER LEVEL BEAM FOR FOLDING DOOR. COORDINATE HEIGHT WITH FOLDING DOOR SUPPLIER. CONNECTION OF FOLDING DOOR TO BEAM TO BE COORDINATED BY FOLDING DOOR SUPPLIER. 5 S-MB-5.25 DIAG BRACE L76x76x6.4
