A structural steel column sits centered on a concrete pier foundation labeled PC-4 with a top of concrete elevation of 11'-0". Four anchor bolts are arranged symmetrically around the column profile. Existing empty electrical conduits pass horizontally through the foundation zone.
E E E E 3'-9" 3'-9" 5'-3" 7'-6" (E) EMPTY ELECTRICAL CONDUIT. PC-4 T.O.C. 11'-0"
