Simpson LSTA24 structural straps tie timber framing members together at an exterior or open condition. A beam located below is positioned per plan typically, with equally spaced fasteners across the intersecting straps.
BEAM BELOW PER PLAN, TYP. EQ EQ OPEN OR EXTERIOR SIMPSON LSTA24 STRAP
