A hollow structural section is placed on each side of the metal deck opening referencing structural details. Additional reinforcing is provided for holes ranging from thirteen to twenty-four inches maximum. The hollow structural section attachment extends a minimum of three flutes past each end of the opening.
HSS EACH SIDE OF OPENING REF. SS050 DECK FLUTE TYP. REINFORCING AT HOLES 13" TO 24" MAX. 24" MAX. HOLE EACH END EXTEND (3) FLUTES MIN. HSS ATTACHMENT TO DECK
