A wide-flange beam connects to a wide-flange column using a bolted shear plate welded to the column flange. The column is reinforced with horizontal continuity plates aligned with the beam flanges. A detail callout directs the builder to check sheet 1/S7.03, and an additional note references sheet 2/S7.04 for more information.
