Concrete beam reinforcement features top reinforcing bars detailed with standard hooks terminating into the support. Bottom beam reinforcing bars extend continuously through the assembly. The concrete section provides a typical one and one-half inch clearance to reinforcement per plan, with beam dimensions and reinforcement sizes determined by scheduling tables.
TYP 1 1/2" CLR "H" "W" BM TOP REINF PER TABLE w/ STD HOOK BOTTOM BM REINF PER TABLE BM & REINF PER TABLE PER PLAN
