A horizontal WT brace connects to a structural steel beam per plan using a three-eighths-inch steel plate gusset. Four seven-eighths-inch diameter A325 bolts secure the brace to the plate, and two seven-eighths-inch diameter A325 bolts connect the plate assembly to the beam flange. Sections A-A illustrate the framing details featuring L5x3x3/8 angles with long legs horizontal connected with one seven-eighths-inch diameter A325 bolt.
WP HORIZONTAL WT BRACE PER PLAN STL PL3/8 BM PER PLAN (4) 7/8"Ø A325 BOLTS (2) 7/8"Ø A325 BOLTS A A SECTION A-A 1 1/2" 3" 2" 2" 3" 2" TYP 2" TYP L5x3x3/8 (LLH) (1) 7/8"Ø A325 BOLTS SECTION A-A 1 1/2" 3" 2" 2" L5x3x3/8 (LLH)
