Cold-formed steel wall studs frame into a sixteen-gauge track at the window head with an in-plane slip connection secured by three number ten sheet metal screws with horizontal slots. At the king stud connection, provide a row of number ten sheet metal screws at each side for a total of six fasteners. At the hollow structural section, provide two number fourteen self-tapping screws at each side for a total of four fasteners.
L6 CONT & FASTENERS WALL STUDS PER PLAN 4 S6.1.4 HEAD T.O WINDOW (3) #10 SMS w/ HORIZONTAL SLOT 16GA TRACK NOTE: AT KING STUD CONNECTION, PROVIDE A ROW OF #10 SMS AT EACH SIDE, (6) TOTAL. AT HSS, PROVIDE (2) #14 TEKS EACH SIDE, (4) TOTAL. TYPICAL CONDITION HSS CONDITION 4 S5.3.3 BM PER PLAN PLAN VIEW B-B 1'-4" MAX B B SECTION AT BM STL ASSEMBLY AS IN DETAIL S6.1.4 1 1/2" = 1'-0" 6 LIGHT GAUGE STUD FRAMING AT WINDOW HEADS-IN-PLANE SLIP LGD6
