Small penetrations in composite metal decks up to thirteen inches in diameter or square require maximum cuts of two webs and one low flute, centered on the deck low flute. Randomly located openings up to six inches maximum do not require reinforcing and permit a maximum of one low flute cut.
HOLE CENTERED ON DECK LOW FLUTE MAX. (2) WEBS AND (1) LOW FLUTE CUT MAX. (1) LOW FLUTE CUT OR SQ. MAX. 13" DIA. LOCATED AT RANDOM 6" MAX. HOLE WITHOUT REINFORCING NOTES:
