A hollow structural section diagonal brace connects to a hollow structural section column using standard fillet welds specified at one-quarter inch typical on three sides with a minimum five-inch length. Fillet welds sized at one-quarter inch connect the members as noted on the structural drawing set. General notes reference sheet specifications for additional hollow structural section beam to column and beam to beam connections.
1/4 1/4 (1/4) (1/4) TYP. 3 SIDES TYP. MIN. 5" (t-1/16) NOTES: 1. REF 14/S6.2 FOR HSS BEAM TO HSS COLUMN CONNECTIONS. 2. REF 15/S6.2 FOR HSS BEAM TO HSS BEAM CONNECTIONS. 3. t IS THE THICKNESS OF ANGLE.
