A beam-to-column connection in a braced frame system features diagonal braces intersecting at a common working point. Gusset plates are provided by the buckling-restrained brace manufacturer and connect to the braces using multiple rows of bolts. Stiffener plates are installed on the column web per the buckling-restrained brace manufacturer requirements to handle concentrated loads at the connection zone. Diagonal braces are positioned as indicated per the elevation and where required by the structural layout.
W.P. BRACE PER ELEVATION GUSSET BY BRB MFR STIFF PL PER BRB MFR BRACE WHERE OCCURS
