A reinforced concrete pile cap supports a concrete pedestal and a column centered on grid. Sixteen total number 4 reinforcing bars are distributed with four at each side of the pedestal. Anchor bolts extend through the pedestal down into the pile cap. The assembly connects to piles sized and spaced per plan, with edge of grade beams shown beyond.
a b PILE CAP "t" SEE DETAILS 2'-0" MIN. 2" MAX. 2" MAX. GRID PILE, TYP., SEE PLAN PILE CAP, SEE PLAN EDGE OF GRADE BM., BEYOND T.O.P.C. B.O.P.C. SEE PLAN T.O. PEDESTAL (-4'-0") ℄ COL. & PILE CAP #4 6" (16 TOTAL) DISTRIBUTED 4 AT EA. SIDE OMIT BARS WHEN
