Cold-formed steel stud framing utilizes track of the same gauge as the studs, featuring cut flanges and a web bent up with two number ten self-tapping metal screws to the stud web. A maximum one-half inch clearance is provided typically between components. Additional connection details utilize an L200x200-54 angle matching the stud width fastened with two number ten self-tapping metal screws on each face.
CUT FLANGES TRACK W/ SAME GAGE AS STUDS STUD, TYP TRACK W/ SAME GAGE AS STUDS, CUT FLANGES & BEND WEB UP W/ (2) #10 SMS TO STUD WEB 1/2" MAX TYP 1/2" MAX TYP (2) #10 SMS EA FACE L200x200-54 x STUD WIDTH C A 33 MIL & LIGHTER STUDS B 43 MIL & HEAVIER STUDS C
