An MC6x15.1 channel stair stringer with a one-half-inch cap plate connects to a one-half-inch end plate via a three-sixteenth-inch fillet weld, with side, top, and bottom welds ground smooth. Two three-quarter-inch-diameter by three-and-a-half-inch-embedment Hilti HIT-HY 200 V3 adhesive anchors secure the end plate to a concrete wall sized per plan. The connection interfaces with a four-inch slab on grade reinforced with number four dowels at twelve inches on center. Treads and risers are coordinated per architectural drawings.
ARCH SEE 2" 3/16 2 CHANNEL STRINGER SEE STAIR PLAN SEE ARCH FOR TREAD & RISER MC6x15.1x1'-2" W/ 1/2" CAP PL & (2)3/4"Ø x 3 1/2" EMBED HILTI HIT-HY 200 V3 HAS ADHESIVE ANCHORS CENTERED (ASSEMBLY CENTERED ON STAIR STRINGER) 1/2" END PL 3/16 STRINGER TO END PL GRIND SIDE, TOP & BOTTOM SMOOTH GRIND SMOOTH 4" SLAB ON GRADE SEE PLAN 8" 1/2" 4" 6" 4" #4 DWLS @ 12"OC 2'-0" 2'-0" SEE PLAN T/SLAB CONC WALL SEE PLAN
