A concrete step beam configuration with slab and reinforcement sized per plan. The assembly comprises concrete slab reinforcement, beam top and bottom reinforcement, and beam ties consisting of number four bars at twelve inches on center minimum. For the two pour condition, an intentionally roughened surface to one-quarter inch amplitude is specified along the vertical joint with continuous number four horizontal bars at twelve inches on center each face. A one-and-one-half-inch concrete clearance is maintained typically unless otherwise noted.
CONC SLAB & REINF PER PLAN, TYP BEAM TOP REINF PER PLAN BEAM TIES PER PLAN (#4 @ 12"OC MIN) BEAM BOT REINF PER PLAN PER PLAN TYP UNO 1 1/2" CLR CONC SLAB & REINF PER PLAN, TYP BEAM TOP REINF PER PLAN BEAM TIES PER PLAN (#4 @ 12"OC MIN) #4 HORIZ @ 12"OC EF CONT BEAM BOT REINF PER PLAN 48" MAX PER PLAN AT SINGLE POUR AT TWO POUR PROVIDE INTENTIONALLY ROUGHENED SURFACE TO 1/4" AMPLITUDE T/SLAB PER PLAN T/SLAB PER PLAN PER PLAN TYP 1 1/2" CLR T/SLAB PER PLAN T/SLAB PER PLAN BIM 360://PresidioBayVentures - 200 Kansas/Struct-19081-0118-R2020.rvt
