S-9SHYD — Steel Beam Connection to Steel Column with Deflection Joint

Structural · S-9SHYD

Steel Beam Connection to Steel Column with Deflection Joint

Materials

Elements

Columns Beams Walls Decks Arches Connections / Plates

About this detail

A steel beam connects to a vertical steel column adjacent to a concrete over steel deck floor system. A deflection joint interfaces with a steel tube and the exterior wall system, which is coordinated per architectural drawings. Additional structural framing links through detail reference D1 on sheet SF601.

STEEL COLUMN STEEL BEAM EXTERIOR WALL SYSTEM SEE ARCH DEFLECTION JOINT CONCRETE OVER STEEL DECK SF601 D1 STEEL TUBE CONCRETE OVER STEEL DECK

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
