Two-sided structural steel connection framing infill beams into a supporting girder web using bolted shear tabs. A structural tee section matches the beam flange width and is welded to the bottom flange with a quarter-inch fillet weld when beam depths differ by more than one inch. The connection incorporates complete joint penetration welds at the top and bottom flanges with a maximum one-inch clearance where required. Bolt count, size, spacing, and edge distance comply with American Institute of Steel Construction specifications.
BEAM TO BEAM CONNECTION (TWO SIDED CONNECTION) F BEAM DEPTH DIFFERENCE > 1" BEAM DEPTH DIFFERENCE < 1" NOTE: WELD BACKUP PLATES NOT SHOWN FOR CLARITY TO STEEL NO & SIZE OF BOLTS (SEE NOTE 3) FOR BOLT SPACING AND EDGE DISTANCE SEE AISC SPECIFICATIONS, TYP SHEAR TAB (SEE NOTE 3) GIRDER (SEE PLAN) WT TO MATCH FLANGE WIDTH OF BEAM SHOWN ON PLAN THUS: 2'-0" 1/4 WT TO BEAM SEE NOTE 3 1" MAX . CP T&B FLANGES, TYP SEE NOTE 3 TYP M
