Reinforcing bars feature lap splice lengths separated by dimension b, including a maximum one-to-six shop offset bend for alignment. Non-staggered splices align the lap lengths directly alongside each other, while staggered splices offset the lap locations along the bar length.
DIAGRAM AT STAGGERED SPLICES 1:6 MAXIMUM SHOP OFFSET BEND LENGTH SPLICE LENGTH SPLICE db LENGTH SPLICE DIAGRAM AT NON- STAGGERED SPLICES B B
