Two structural braces intersect at a common work point above a floor or roof beam supporting a concrete over metal floor deck. Stiffener plates are detailed along the beam, with the specific plate number, size, and location to be designed by the buckling-restrained brace supplier. Connections for beams near-side or far-side are located per plan or roof deck requirements.
STIFF PL NUMBER, SIZE AND LOC TO BE DESIGNED BY BRB SUPPLIER BM CONC OVER MTL FLR DECK WP CONNECTION FOR BM NS OR FS, SEE PLAN OR ROOF DECK STIFF PL NUMBER, SIZE AND LOC TO BE DESIGNED BY BRB SUPPLIER BM CONC OVER MTL FLR DECK WP CONNECTION FOR BM NS OR FS, SEE PLAN OR ROOF DECK
