A pin-ended buckling-restrained brace connects to a wide-flange column and wide-flange beam using a welded gusset plate reinforced on both sides. The beam top and bottom flanges are welded to the column with connection details referenced to other sheets. The pin passes through the gusset plate and the brace end, aligning the working points along the column, beam, and brace centerlines.
7 S4-101 8 S4-101 11 S4-100 A PIN-ENDED BRB CONNECTION WELD T&B FLANGES SEE OR WF BM SEE PLAN WF COL SEE PLAN GUSSET REINF PL BOTH SIDES BRB SEE PIN GUSSET PL CL COL CL BM CL BRACE CL COL
