A concrete slab on steel deck bears on the top flange of a built-up wide flange steel beam. Shear studs are spaced per plan along the top flange. Typical L4x3x1/4 angles are attached to support framing with a three-quarter inch clearance gap.
BU WF BEAM TYP 3/4" TOP FLANGE ≤3" L4x3x1/4 LLV, TYP TYP TOP FLANGE STUDS PER PLAN PER PLAN TOC SLAB ON STL DECK
