Typical slab edge condition at structural steel columns for both parallel and perpendicular web orientations. An L2x2x3/16 angle is placed at each flange with an edge form sized per Table K.1, providing a three-sixteenth inch minimum slab edge. A closure plate is held back to clear the weld by a maximum of one-half inch typically. Welds secure the assembly as indicated in the callouts.
L2x2x3/16 ES EDGE FORM PER "TABLE K.1", 3/16" MIN SLAB EDGE EDGE FORM PER "TABLE K.1" L2x2x3/16 AT EA FLG TYPICAL EDGE CONDITION AT COLUMN COLUMN WITH WEB PARALLEL COLUMN WITH WEB PERPENDICULAR SLAB EDGE SEE NOTE 6 1/2" HOLD CLOSURE PL BACK TO CLEAR WELD (1/2" MAX), TYP 1/2" TYP
