S-9MC7A — Concrete Over Metal Deck Bearing at Steel Beam

Structural · S-9MC7A

Concrete Over Metal Deck Bearing at Steel Beam

Materials

Concrete Steel Metal (misc.)

Elements

Beams Floors / Slabs Decks

About this detail

A concrete over metal floor deck bears on a structural steel beam sized per plan. The framing includes a secondary steel beam designated LSV, connected to the column with a five-sixteenths inch fillet weld. The main structural steel beam connects to the vertical member with a three-eighths inch fillet weld.

S511 9 S511 STEEL BEAM, SEE PLAN 5/16 3/8 CONCRETE OVER METAL FLOOR DECK, SEE PLAN STEEL BEAM (LSV), SEE PLAN
