A structural steel beam connects to a ledger chord utilizing a five-sixteenths inch fillet weld for the tube to angle connection. The drag tube may be continuous over the steel joist at the contractor's option, with additional information referenced at the steel joist at tilt-up panel detail. A one-foot clearance is maintained at the ledger interface with a half-inch gap specified.
1'-0" 1/2" 4 A. 3 3 5 2 1 7 6 B. REFER TO STEEL JOIST AT TILT-UP PANEL DETAIL FOR INFO. SHOWN BUT NOT NOTED DRAG TUBE MAY BE CONTINUOUS OVER STEEL JOIST AT CONTRACTORS OPTION 5/16 5/16 5/16 TUBE TO ANGLE
