A structural steel beam connects to a concrete tilt-up wall panel using a web connection plate bolted with multiple rows of fasteners. The beam web features horizontal long slotted holes at this connection to accommodate lateral movement. A metal roof deck bears atop the steel beam. At conditions where the beam rests within twelve inches of a panel joint, alternate detailing applies as referenced on sheet S610.
STL BM CONC TILT-UP PANEL, SEE SCHEDS AND ELS HORIZ LONG SLOTTED HOLES IN BM WEB S801 3 AT CONDITION WHERE BEAM RESTS WITHIN 12" OF PANEL JOINT, SEE / (1 S610) FOR DECK EMBED BTWN JSTS, SEE DET / (- ---) MTL ROOF DECK
