A diagonal brace connects to a steel beam supporting metal deck, featuring a three by three by sixteen gauge one-foot-long clip angle secured with four number ten sheet metal screws. The metal deck is fastened to the supporting beam with three number twelve sheet metal screws per flute, aligned either perpendicular or parallel to the brace angle varying from thirty to sixty degrees. A one-inch minimum clearance is maintained at the deck termination. Any removed spray-on fireproofing must be reapplied following installation.
STEEL BEAM NOTES: 1. ALL SPRAY ON FIREPROOFING THAT IS REMOVED SHALL BE REAPPLIED. 2. COORDINATE LOCATION OF DIAGONAL BRACES WITH OTHER TRADES. __ __ E METAL DECK (3) #12 SMS TYP (1) PER FLUTE PERP TO BRACE __ __ F METAL DECK PARALLEL TO BRACE 60° MAX 30° MIN 1" MIN. 3x3x16GA x1'-0" CLIP (4) #10 SMS BRACE PER SECTION METAL DECK PER PLAN (3) #12 SMS TYP 60° MAX 30° MIN 1" MIN. 3x3x16GA x1'-0" CLIP ALIGNED WITH FLUTE (4) #10 SMS METAL DECK PER PLAN
