Buckling-restrained braced frame beams frame into the column flange and column web using bolted connection plates on each side of the column. Continuity plates are provided at the beam flange levels per specific details. Collector connections are detailed on each side of the column with reference to plan details. Frame columns and beams are sized per plan and frame elevations.
COLLECTOR CONN EA SIDE OF COLUMN - SEE DETAIL PLANS & DETAILS 1&5/S5.01C BEAM SEE PLAN & FRAME ELEV FRAME COLUMN, SEE PLAN CONTINUITY PL PER DETAIL 13/S5.01A O BRACED FRAME COLLECTOR TO STEEL BEAM TO COLUMN FLANGE BEAM TO COLUMN WEB O BRACED FRAME COLLECTOR BEAM SEE PLAN & FRAME ELEV FRAME COLUMN, SEE PLAN
