The assembly connects steel beams to the web of a wide flange steel column using bolted web plates and continuity stiffener plates. Stiffener plates are welded to the column flanges and web. Web plates connect the beam web to the column web or to a shared center plate with bolts following typical bolt spacing and edge distance requirements.
BEAM TO WIDE FLANGE COLUMN WEB PLATE CONNECTION BEAM TO WIDE FLANGE COLUMN WEB PLATE CONNECTION WEB PL WEB PL STIFF PL STIFF PL WEB PL WEB PL STL COL STL COL STL BM STIFF PL 2 4 2 2 4 2 4 3 3 1/2" MAX 6 3 6 3" MAX BOLT SPACING AND EDGE DIST, TYP 5 BOLT SPACING AND EDGE DIST, TYP 5 TYP (3) SIDES, TYP
