Studrails are positioned perpendicular to the concrete column and aligned with the column face unless noted otherwise. The layout features evenly spaced studrail assemblies sized per the structural schedule. The concrete column and slab edges are constructed per the architectural and structural plans.
CONC COL PER PLAN EDGE OF SLAB PER PLAN EDGE OF SLAB PER PLAN TYP EQ TYP EQ ALIGN STUDRAILS W/ F/COL, TYP UNO STUDRAIL PER SCHED, TYP
