An MC12x10.6 channel connects to a C8x11.5 channel using a quarter-inch by four-inch full-height connection plate welded with a quarter-inch fillet weld. A typical stiffener plate is welded to the C8 channel with a quarter-inch full-height weld. The C8 channel is secured using three-quarter-inch diameter expansion anchors spaced at a maximum of one foot six inches on center.
MC12x10.6 3/4" DIA. EXP. ANCHORS AT 1'-6" O.C. MAX. C8x11.5 1/4" x 4" FULL HT. CONNECTION PL C8 TO MC12 MC12x10.6 TYP. STIFF. PL. TO C8 WELD 1/4 x FULL HT. SIGNLE PL CONN.
