A metal deck bears adjacent to the bottom flange of a steel beam, supported by a continuous 4x4x1/4 inch structural angle that can be inverted as required. A continuous 3/16 inch butt weld secures the connection where required, with a one-half inch minimum clearance maintained above and below the flange interface. A continuous bent plate is provided at the deck transition. Where the deck slopes relative to the beam, transitional detailing is required per architectural drawings.
3/16 CONT. BENT PL 1/4"x DECK AT BEAM BOTTOM FLANGE 3/16 3-12 cont. butt weld where reqd. L 4x4x1/4 CONT. (INVERT L IF REQD.) NOTE: WHERE DECK SLOPES RELATIVE TO THE BEAM, TRANSITION BTWN. DETAILS AS REQD. & DETAILS PER ARCH'L 1/2" MIN. 1/2" MIN.
