This structural section details a concrete foundation wall and footing supporting a concrete slab at a loading dock. The assembly incorporates an embed angle at the slab edge, adjacent to an overhead sectional door and four-inch dock bumpers. Extruded polystyrene board insulation with an R-10 rating lines the exterior of the foundation wall, separated from the finished pavement by a half-inch asphalt impregnated fiber strip. A drainage course rests beneath the concrete slab, which slopes at one-quarter inch per foot starting from the interior face of the wall. A typical reveal chamfer is provided at the exterior concrete corner.
4" DOCK BUMPERS OVERHEAD SECTIONAL DOOR CONCRETE SLAB. SEE STRUCTURAL DRAWINGS FOR SIZE AND REINFORCING 1/2" ASPHALT IMPREGNATED FIBER STRIP, TYP. FINISHED PAVEMENT RE: CIVIL DRAWINGS CONCRETE FOOTING & FOUNDATION RE: STRUCTURAL DWGS FOR SIZE AND REINFORCING EXTRUDED-POLYSTYRENE BOARD INSULATION (R-10) DRAINAGE COURSE EMBED ANGLE, RE: STRUCT. SLOPE (1/4" : 12") EDGE OF SLAB, BEGINNING AT INTERIOR FACE OF WALL. TYP. REVEAL CHAMFER
