Steel deck orientation and perimeter edge conditions are supported by structural steel beams. The assembly incorporates continuous twelve-gauge and sixteen-gauge bent edge plates welded to the supporting beams. Three-quarter-inch diameter fasteners are spaced at twelve inches on center. Additional support is provided by an L4x4x1/4 angle spaced at a maximum of eight feet on center per detail 9D.
STEEL DECK PERPENDICULAR TO EDGE BM STEEL DECK PARALLEL TO EDGE BM 16 GA BENT EDGE PL CONT STEEL DECK SEE PLAN STEEL DECK SEE PLAN 12 GA CONT BENT PL (WELDED TO BEAM) 8" MAX 2'-0" MAX 3/4"Ø @12" OC STEEL DECK SEE PLAN 12 GA CONT BENT PL (WELDED TO BEAM) 2'-0" MAX L4x4x1/4 @ 8'-0" MAX PER DETAIL 9D/- 3/4"Ø @12" OC (0'-8" MAX) A (2'-0" MAX) B 2" TYP
