Reinforcing steel bars overlap within structural concrete members using a Class "A" lap splice. The overlapping bars maintain a minimum clear distance of one and one-half inches. Splice lengths measure a minimum of twelve bar diameters or twelve inches, whichever is greater. These lap splice requirements apply to boundary elements, columns, beams, walls, and slabs.
BOUNDARY, COLUMN AND BEAM REINFORCING SPLICE DETAIL SPLICE DETAIL WALL OR SLAB REINFORCING B A 12" MIN 12d OR d 1 1/2" MIN CLASS "A" LAP SPLICE
