A structural steel davit support assembly framing into a W12x19 beam and column configuration, shown in plan and elevation. The davit socket pedestal mounts atop a support plate, stabilized by three-eighths-inch stiffener plates on each side and connected with quarter-inch fillet welds. A half-inch by four-inch plate sized to the beam width plus one inch attaches to the beam flanges with quarter-inch fillet welds. Additional three-eighths-inch stiffener plates reinforce the beam web and column connection.
PLAN PL 1/2"x4"x BEAM WIDTH +1" w/ 1/4" FILLET WELD TO FLANGES (SEE DETAIL E FOR COL ROTATED 90°) BEAM SEE PLAN DAVIT SOCKET PEDESTAL 3/8" STIFF PL EACH SIDE COLUMN SEE PLAN W12x19 TYP UON BEAM SEE PLAN 3/8" STIFF PL EACH SIDE 2 1 BEAM SEE PLAN 1/4 1/4 BEAM WEB TO STIFF PL (3'-0" MAX) SEE PLAN 3/8 TYP ALL SIDES
