A buckling-restrained braced frame double brace connection intersects a beam and column assembly. Four diagonal buckling-restrained braces connect through gusset plates, with gusset plate sizes, connection bolts, and welds designed per the buckling-restrained braced frame manufacturer. One-half inch stiffener plates and web stiffeners are spaced equally across four spaces, accompanied by doubler plates as required by the manufacturer.
WORK POINT GUSSET PL SIZE - PER BRBF MANF'R. STIFFENER PL AS REQ'D. BY BRB MANF'R. CONNECTION BOLTS DESIGNED BY BRB MANF'R. BRB - BY OTHERS WELD PER BRB MANF'R., TYP. STIFFENER PL AS REQ'D. BY BRB MANF'R., TYP. EQ. EQ. SPACE STIFFENERS IN 4 EQUAL SPACES DOUBLER PL AS REQ'D. BY BRB MANF'R. WELD SIZE PER BRBF MANF'R. BY BRB MANF'R. PL1/2 STIFFENER PL
