A reinforced concrete slab on grade bears on a concrete foundation wall with panel reinforcement sized per plan. Vertical and horizontal reinforcement utilizes number 4 rebars spaced at 18 inches on center with 2 inches of concrete clearance. Glazing above is coordinated with architectural drawings.
GLAZING SEE ARCH CONC SLAB ON GRADE SEE PLAN #4 @ 18"OC PANEL REINF SEE PLAN 16" 36" 2" CLR
