A customized window frame profile incorporates internal lead lining as required for radiation shielding or specialized acoustic attenuation. A removable stop secures the glazing unit while allowing future access or replacement. Dimension strings establish a throat opening width of two inches alongside equal spacing increments and precision offsets.
THROAT OPENING 5/8" 2" 1 1/4" 1 1/4" 1/2" 1/2" EQ EQ REMOVABLE STOP LEAD LINING AS REQD
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
