A buckling-restrained brace connection frames into a steel column and beam intersection. The gusset plate is positioned with working points specified at the face of the column and beam for the designated frame, utilizing adjacent doubler plates as required by the connection schedule. References direct the builder to specific layout procedures and conditions for doubler plate installation.
L gc APPROX COL 4 L gb APPROX 6 SEE W b BEAM 90° 6 SEE W c W.P. @ CNTR OF COL & 1/2 ACTUAL BM DEPTH X X 7 4 1 L wc L wb 8 TYP SEE DETAIL 23 FOR CONDITION WHEN DOUBLER PLATE IS REQUIRED BY COREBRACE CONNECTION SCHEDULE. B DOUBLER PLATE B SEE DOUBLER PLATE B SEE SEE DETAILS 1, 2, AND 3 FOR BRB & GUSSET LAYOUT PROCEDURE. A W.P. @ FACE OF COL & BM FOR FRAME NE6C
