This structural detail shows a steel gusset plate configured with two rows of bolt holes spaced at three inches on center. The plate features a one-inch chamfer at its corner. Edge distances and fastener spacing dimensions are explicitly noted with one and seven-eighths inch and one and one-half inch dimensions.
